F5-BIG-BT-R5600 Best Bundle
- Designed for mid-to-large businesses needing secure, high-speed core network access.
- 60K SSL TPS and hardware compression easily handle high-traffic web security workloads.
- 128GB memory and 8-tenant support make it ideal for consolidating critical services.
- Built-in 100G/40G ports seamlessly integrate with enterprise backbones.
- Key Features
- Specification
- FAQ
F5-BIG-BT-R5600: All-in-one Gateway for High-speed Core Network Integration
The F5-BIG-BT-R5600 is a premium “Best Bundle” solution designed for large-scale IT consolidation. Compared to the BT-R4000 series, like F5-BIG-BT-R4800, it delivers a significant hardware leap — introducing native 100G/40G ports, doubling memory to 128GB, and greatly enhancing SSL performance. These upgrades make the R5600 a true all-in-one platform, ideal for core deployments handling application delivery, security, and access control in industries like finance, education, and healthcare.
F5-BIG-BT-R5600 Key Features
Enterprise-Grade Integrated Platform
With balanced 60Gbps throughput and robust hardware, the R5600 confidently supports all “Best Bundle” modules — LTM, AWF, APM, and AFM — at once. It’s the ideal choice for centralizing key services on a single, high-performance platform.
Powerful Concurrent Security Processing
Delivering up to 60,000 SSL TPS and 35Gbps hardware compression, the R5600 offloads intense cryptographic and inspection workloads. This ensures strong HTTPS traffic decryption, deep threat detection (AWF), and high-performance access control (APM), all without sacrificing speed or user experience.
High-Density IT Consolidation
With 128GB RAM and virtualization for up to 8 tenants, the R5600 is built for large-scale service integration. You can consolidate legacy devices like standalone WAFs or VPN appliances onto one system, reducing data center footprint, cost, and complexity.
Core Network-Ready 100G Interfaces
The R5600 features two 100G/40G QSFP+ ports, ready to connect directly to your data center’s core or aggregation layer. This ensures the gateway won’t become a network bottleneck and keeps you ready for future bandwidth demands.
F5-BIG-BT-R5600 Datesheet
- L4/L7 Throughput: 60 Gbps / 60 Gbps
- Max L4 Concurrent Connections: 75M
- SSL TPS (2K Keys): 60,000
- Memory: 128 GB DDR4
- Primary Ports: 2x 100G/40G QSFP+, 8x 25G/10G SFP+
- Hardware Redundancy: Optional Dual PSU, Single Drive
Traffic Processing and Acceleration
Intelligent Traffic Processing:
- L7 requests per second: 2.5M
- L4 connections per second: 1M
- L4 HTTP requests per second: 18M Maximum
- L4 concurrent connections: 75M
- Throughput: 95 Gbps/60 Gbps L4/L7
Hardware Offload SSL/TLS:
- 60K TPS (2K SSL TPS)
- 30K TPS (ECDHE-ECDSA P-256 TPS)
- 30K TPS (ECDHE P-256-RSA 2k TPS)
- 35 Gbps bulk encryption
System Architecture & Logical Design
- Hardware Compression: 35 Gbps
- Software Architecture: 64-bit TMOS; 64-bit F5OS
- Multi-Tenancy: 8 Tenant
- Processor: 8-Core Intel® Atom® processor(12 CPUs available for Tenancy)
- Memory: 128GB DDR4
- Hard Drive: 1TB M.2 SSD
Network Interfaces & Connectivity
- Management Ports:
- 1x 1000BASE-T,
- 1x USB 3.0,
- 1x serial console
- 100/40 Gigabit Fiber Ports: 2× 100 G/40 G QSFP+/QSFP28 ports
- 25/10 Gigabit Fiber Ports: 8 × 25 G/10 G/10 G SFP+/SFP28
Power Supply & Energy Consumption Management
Power Supply:
- 1 x 650 W 100-240 VAC (+/- 10%) AUTO Switching Platinum,
- Dual DC PSU Optional
Typical Consumption: 425W (single power supply, 48V DC or 110V AC input)
Input Voltage / Typical Heat generated:
- Single Power supply
- 110 VAC input: 1455 BTU/hour
- 230 VAC input: 1420 BTU/hour
Physical Specifications & Environmental Adaptation
Dimensions: H: 1.72 inches (4.37 cm) x W: 17.1 inches (44.2cm) x D: 30.6 inches (77.72 cm). 1U industry standard rack-mount chassis
Weight: 36.0 pounds (916.33kg) with two power supply units (PSUs) (per unit)
Operating Temperature: 32 to 104°F (0 to 40°C)
Operational Relative Humidity: 5% to 85% (40 C) non-condensing
Safety Certification & Compliance
Hardware Certification Model: r2000
Safety Agency Approval:
- ANSI/UL 60950-1-2014
- CSA 60950-1-07, including A1:2011+A2:2014 IEC 60950-1:2005,
- A1:2009+A2:2013
- EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
- IEC 62368-1:2014 (Second Edition) EN 62368-1:2014+A11:2017
- CSA C22.2 No. 62368-1-14, UL 62368-1, 2nd edition
Certifications / Susceptibility Standards:
- FCC Class A (Part 15), lc Class A;
- VcCl Class AEN 55032:2012/AC:2013 Class A
- EN 55035:2017
- EN 300 386 V1.6.1 (2012)
- NEBS Level 3 compllant
Can the F5-BIG-BT-R5600 handle all the “Best Bundle” services for a large company?
Yes, it’s designed for that. With 60G of throughput, 128GB of RAM, and 12 dedicated business vCPUs, it has the resources to concurrently run LTM, AWF, AFM, and APM for a large enterprise with significant traffic.
How many separate services can I realistically consolidate with its 8-tenant capability?
You can create up to 8 fully isolated virtual ADCs. This is ideal for consolidating services for multiple departments, different applications (e.g., web, email, API), or for creating separate production, staging, and development environments on a single appliance.
Is the BT-R5600 a good long-term investment?
Absolutely. Its powerful hardware and native 100G ports make it a future-proof platform. It allows you to consolidate your current needs while providing massive headroom for traffic growth and future network upgrades.
